Quick Details

  • Products Status: Stock
  • Application: Other
  • Type: Other
  • Form Factor: BTX
  • Material: Aluminum Alloy
  • Style: With Fan
  • Front Ports: USB
  • Brand Name: Antminer
  • Model Number: AntMiner S9
  • Place of Origin: Guangdong, China (Mainland)
  • Color: Silver
  • Use: SHA256 Mining
  • Standard Speed: 11.85TH/s ±5%
  • Power Consumption: 1172W + 7%
  • Power Efficiency: 0.1 J/GH + 7%
  • Cooling: 2x 12038 fan
  • Chips number: 189pcs BM1387
  • Dimensions: 350mm(L)*135mm(W)*158mm(H)
  • Weight: 5.5KG

Packaging & Delivery

Packaging Details Carton box package
Delivery Time Shipped in 2 days after payment
2016 Factory price antminer s9 14Th/s 22nm bitcoin miner s9 14th/s with power supply bitcoin miner s9Product Description


S9 Specifications:

1. Hash Rate: 13.5TH/s ±5%

2. Power Consumption: 1300W + 7% (at the wall, with APW3 ,93% efficiency, 25C ambient temp)

3. Power Efficiency: 0.1 J/GH + 7%(at the wall, with APW3 93% efficiency, 25°C ambient temp)

4. Rated Voltage: 11.60 ~13.00V

5. Chip quantity per unit: 189x BM1387

6. Dimensions: 350mm(L)*135mm(W)*158mm(H)

7. Cooling: 2x 12038 fan

8. Operating Temperature: 0 °C to 40 °C

9. Network Connection: Ethernet

10. Default Frequency: 650M


1. Power consumption figures will vary with your PSU's efficiency, the ambient operating temperature and the accuracy of the power meter.

2. PSU: A power supply unit is not included, and you will need to provide an ATX PSU. There are 3 PCI-e connectors for +12V DC input on each hashing board and all 3 are required. Do not connect more than one PSU to the same hashing board!

3.Bitmain recommends theAPW3-12-1600-B2 power supply for use with the S9. One power supply support one S9.

4. Separate power supply to control board: there is one additional 6pin PCI-e connector on the IO board which must be connected to the PSU to get power. Be sure to power on the miner after ALL the 10x PCIE connectors connected to power supply.

This Antminer S9 is not only the first 16nm miner for retailuse but using less than half the energy per gigahash of the S7, but it is also our most powerful miner to enter mass production . At 0.098 joules per gigahash, this is the most efficient machine available to the bitcoin mining public.

Detailed Images

SKYPE amanda2007520

Whatsapp: 0086 15989304391



Skype: amanda2007520
Whataspp: 008615989304391
Address: D Blog Junfeng Technology Park, Lezhujiao, Jiuwei Xixiang Baoan, Shenzhen China.
Tell: 86 755 27902045 Mobile: 86 15989304391
